1 Way IN + 2 Ways OUT

3 Polos + Tierra 1 Way IN + 2 Ways OUT M139MN--/4

Modelo M139MN--/4

M139MN--/4

Conector:	3 Polos + Tierra 1 Way IN + 2 Ways OUT
Tensión nominal:	450V
Corriente nominal:	16A
Temperatura de funcionamiento:	T -40°C + 125°C
Tipo de prisioneros para la conexión de los conductores:	soporte con prisionero
Capacidad de conexión de los prisioneros:	0.50 ÷ 4.00 mm²
Diámetros de los cables:	8.0 ÷ 17.0 mm
Categoria de sobretension:	II
Grado de contaminacion:	II
Grado de protección:	IP68
Conforme a las normas:	EN 60998-1 / EN60998-2-1 / EN60529-1 / EN60335
Marcas de conformidad:	ENEC 03
Cuerpo:	PA66
IP68 WATERTIGHT CLAMP CONNECTION DEVICE WITH 3 POLES + GROUND 1 WAY IN 1 WAY OUT (M139MNAA/4: VERSION WITH GLANDS FOR CABLES WITH DIAMETER BETWEEN 7 AND 13.5 MM WITH 24 MM HEXAGONAL KEY NUT - M139MNBA/4: VERSION WITH LINE IN GLAND FOR CABLES WITH DIAMETER BETWEEN 8 AND 17 MM WITH 29 MM HEXAGONAL KEY NUT AND LINES OUT GLANDS FOR CABLES WITH DIAMETER BETWEEN 7 AND 13.5 MM WITH 24 MM HEXAGONAL KEY NUT - M139MNBB/4: VERSION WITH GLANDS FOR CABLES WITH DIAMETER BETWEEN 8 AND 17 MM WITH 29 MM HEXAGONAL KEY NUT)
REACH - SCIP registro:: 7792a36c-0519-45b0-8dfd-6bf309c5b14c
