1 Way IN + 2 Ways OUT

4 Pinos + Terra 1 Way IN + 2 Ways OUT M139MN--/5

Modelo M139MN--/5

M139MN--/5

Conector:	4 Pinos + Terra 1 Way IN + 2 Ways OUT
Tensão nominal:	450V
Corrente nominal:	16A
Tempertatura de trabalho:	T -40°C + 125°C
Tipo de conexão para cabos:	conexão por parafuso
Capacidade de conexão:	0.50 ÷ 4.00 mm²
Diâmetros de los cabos:	8.0 ÷ 17.0 mm
Categoria sobrevoltagem:	II
Grau de poluição:	II
Grau de proteção:	IP68
Conforme normas:	EN 60998-1 / EN60998-2-1 / EN60529-1 / EN60335
Selos de aprovação:	ENEC 03
Corpo:	PA66
IP68 WATERTIGHT CLAMP CONNECTION DEVICE WITH 4 POLES + GROUND 1 WAY IN 1 WAY OUT (M139MNAA/5: VERSION WITH GLANDS FOR CABLES WITH DIAMETER BETWEEN 7 AND 13.5 MM WITH 24 MM HEXAGONAL KEY NUT - M139MNBA/5: VERSION WITH LINE IN GLAND FOR CABLES WITH DIAMETER BETWEEN 8 AND 17 MM WITH 29 MM HEXAGONAL KEY NUT AND LINES OUT GLANDS FOR CABLES WITH DIAMETER BETWEEN 7 AND 13.5 MM WITH 24 MM HEXAGONAL KEY NUT - M139MNBB/5: VERSION WITH GLANDS FOR CABLES WITH DIAMETER BETWEEN 8 AND 17 MM WITH 29 MM HEXAGONAL KEY NUT)
REACH - SCIP registro:: 7792a36c-0519-45b0-8dfd-6bf309c5b14c
